Electromechanical lock for door
Type: Z-7 EHT

Advantages:

	Low price
	Office mode
	Hotel mode
	Copy Protection Card
	Stainless steel housing
	Connection of a push button door opening
	Programming from a PC (via adapter Z-2 или adapter RF1996 )
	No less than 25,000 openings on a single charge
	Simple installation and setup
	Mechanical locking key

Technical specification:

Operating frequency: 125 KHz
Card Reader & trinkets standard: EM Marine, HID ProxCard II, Temic
Number of keys / cards (max): 1364pcs.
Number of recorded events (max): 1000 times.
Built-in non-volatile memory (EEPROM)
Reading range: 2-4 cm
Current consumption: 30uA (pending)
Dining: 1.5V X 4 pcs. standard AA batteries
Sound / light indication: buzzer, two LEDs
Adjustment of lock from 0 to 220 sec.
Operating temperature: -40 ° C +60 ° C (excluding battery)
Case Material: Stainless Steel
Colour: silver, gold

*Mode Office - with a master card or computer creates a database key-card, and stored in the controller lock. When the card is attached to a reader of the lock, the buzzer will sound and blue LED will be flashing, if the card is authorized to access. While the blue LED flashes, it is necessary to turn the handle and open the door before the time runs out to open the door (the default is 3 seconds.) If the card has no right to access, the buzzer sounds and red LED flashes and by turning the knob, the door will not open.

*Mode Hotel - each time when administrator registers new card by Software Hotel guest brings this card to unlock his room, so activates the lock and enters the room. "Guest Card" dynamically changeable. That is, when you change or lose "Guest Card" by some algorithm known castle, previous or lost "Guest Card" becomes invalid. You can create cards for staff and other persons with specific functions. To gain access to the computer system requires coding card statement with the appropriate personal password. With this issue cards can only designated operators.

Examples:

Lock ILogic Z-7EHT - this proximity reader, standalone controller and a full locking system. To open the door from the outside to bring a card, and inside just press the handle on the inside of the door. Lock powered by 4 AA-size batteries. Attractive design, rugged construction, ease of programming and installation, "advanced" functionality - all will use the lock in hostels, camps and college campuses, commercial and public buildings of any purpose.
